HZXZ Rotary Vibration Cleaner
Function: combined with rotary cleaning and vibration screening, particularly suitable for granular materials large capacity cleaning of large, small and light impurities, and large capacity grading.
Details
HZXZ Rotary Vibration Cleaner
Description
Function: combined with rotary cleaning and vibration screening, particularly suitable for granular materials large capacity cleaning of large, small and light impurities, and large capacity grading.
Advantages
- Strong overall structure, large capacity;
- Smooth plane rotation, excellent effect for cleaning and grading;
- Universal joint hanger rod, durable for long service life, low failure rate;
- Reasonable regulation device for grains feeding and mixing, to ensure the screen surface is evenly and fully covered by grains. High efficiency for cleaning and grading;
- Easy replacement of drawer-type full-steel screen layers for different grains.
Specification
| Model |
Capacity (pre-cleaning), t/h |
Capacity (cleaning), t/h |
Screen size |
Speed, r/min |
Power, kW |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|---|
| HZXZ 125х250 | 30 | 10 | 125x250 | 320 | 3 | 2300 | 2988х1995х2105 |
| HZXZ 150х250 | 50 | 30 | 150x250 | 320 | 3 | 2800 | 2988х2205х2105 |
| HZXZ 150х250A | 50 | 30 | 150x250 | 320 | 3 | 2900 | 2988х2205х2105 |
| HZXZ 200х250 | 60 | 40 | 200x250 | 320 | 4 | 3200 | 2988х2705х2105 |
| HZXZ 200х250A | 60 | 40 | 200x250 | 320 | 4 | 3300 | 2988х2705х2105 |
| HZXZ 200х300 | 80 | 60 | 200x300 | 320 | 4 | 3500 | 3549х2755х2105 |
| HZXZ 200х360 | 120 | 80 | 200x360 | 320 | 4 | 3800 | 4150х2815х2105 |
