LD series Electronic Flow Scale
It is suitable for the measurement of production materials such as grain processing, grain depots.
Details
LD series Electronic Flow Scale
Description
- The action mechanism is driven by a unique motor, no working air source is required;
- It is equipped with manual and automatic control modes, which can control the unwinding and feeding mechanism separately by manual operation, which is convenient for cleaning agglomerated and blocked materials. After the "target value" setting is confirmed, the operator only needs to start the "auto" button, and the flow scale will immediately enter the continuous "metering and discharging" operation automatically;
- It has the functions of automatic statistics, printing and data communication of output;
- It has the function of automatic drop correction and over-tolerance alarm.
Specification
| Model |
Power, kW |
Capacity, t/h |
Overall size, mm |
Weighing error |
|---|---|---|---|---|
| 50LD | 0.9 | ≤20 | 1031×1130×1769 | ±0.2% |
| 100LD | 0.9 | ≤40 | 1146×1270×1911 | ±0.2% |
| 200LD | 0.9 | ≤60 | 1320×1400×2856 | ±0.2% |
| 300LD | 0.9 | ≤80 | 1520×1570×2926 | ±0.2% |
| 400LD | 1.1 | ≤100 | 1670×1944×3323 | ±0.2% |
