FSFJ Closed Single/Double Bin Plansifter
FSFJ Closed Single/Double Bin Plansifter is an important equipment for screening and grading materials with different particle size and specific gravity.
Details
FSFJ Closed Single/Double Bin Plansifter
Description
FSFJ Closed Single/Double Bin Plansifter is an important equipment for screening and grading materials with different particle size and specific gravity.It is mainly used in flour, feed, pharmaceutical, chemical, starch and other industries to achieve the purpose of grading materials or removing impurities.
Specification
| Model | Capacity, t/h | Power, kW | Weight, kg | Overall size, mm |
|---|---|---|---|---|
| FSFJ-1x12x83 | 2-4 | 0.75 | 1350 |
1380х1280х2010 |
| FSFJ-1x12x100 | 3-6 | 1.1 | 1680 |
1580х1480х2010 |
| FSFJ-2x12x83 | 4-8 | 1.5 | 2730 |
2120х1480х2010 |
| FSFJ-2x12x100 | 6-10 | 2.2 | 3240 |
2530х1720х2010 |
