NF Grain Flour Milling Machine
NF Grain Flour Milling Machine
Description
NF Grain Flour Milling Machine is mainly used in small size grain flour processing plants. It grinds grains into flour by the grinding roll of the grinder. Then the flour is winnowed and screened by the circular screen.Specification
| Model | Capacity, t/h | Power, kW | Spindle Speed, r/min | Weight, kg | Overall size, mm |
|---|---|---|---|---|---|
| NF-2235 |
0.2-0.3 |
7.5 | 1042 | 600 | 2200х800х3300 |
| NF-2240 |
0.3-0.4 |
11 | 1042 | 700 | 2200х900х3400 |
| NF-2250 |
0.4-0.5 |
15 | 1042 | 800 | 2200х900х3500 |
| NF-2240x2 |
0.6-0.8 |
20.5 | 1042 | 2000 | 4000х1500х3100 |
| NF-2250x2 |
0.8-1 |
22 | 1042 | 2000 | 4000х1800х3400 |
