5XFS series Air-Screen Cleaner
It can clean light impurities through vertical air screen and the vibration sieve can clean big and small impurities.
5XFS series Air-Screen Cleaner
Description
5XFS series Air-screen Cleaner consists of bucket elevator, dust catcher, enclosed rotary unloading valve, vertical screen, and vibration grader.
It can clean light impurities through vertical air screen and the vibration sieve can clean big and small impurities.
The material can be classified into big, medium and small particles with different layers of sieves.
Specification
| Model |
Layer |
Sieve size, mm |
Capacity, t/h |
Power, kW |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|
| 5XFS-7.5C | 4 | 1250х2400 | 7.5 | 8.5 | 1860 | 5100х2050х3430 |
| 5XFS-7.5CS | 4 | 1250х2400 | 7.5 | 8.5 | 1890 | 5100х2050х3430 |
| 5XFS-10C | 4 | 1500х2400 | 10 | 10.5 | 2060 | 5100х2300х3600 |
| 5XFS-10CS | 4 | 1500х2400 | 10 | 10.5 | 2090 | 5100х2300х3600 |
| 5XFS-10CD | 5 | 1500х2400 | 10 | 10.3 | 2560 | 5100х2300х3600 |
