5CX-10 Magnetic Separator
5CX series high-performance magnetic election graders is to separate clods from grain.
Details
Characteristics
Capacity
—
10 t/h
Power
—
1.5 kW
Weight
—
960 kg
Overall size
—
1950×2065×2740 mm
5CX-10 Magnetic Separator
Description
5CX series high-performance magnetic election graders is to separate clods from grain.
When materials are put in a closed strong magnetic field, they will form a stable parabolic movement. Due to the different strength of attraction of the magnetic field, clods and grains will be separated.
Features
- 304 stainless steel sheet metal machine with strict magnetic closure and less magnetic flux leakage;
- The magnetic field strength of magnetic roller is more than 17,000 gauss with good magnetic effect;
- Wide magnetic surface of 1300mm, which ensures the processing capacity and improves the magnetic effect;
- This machine adopts original design of bulk grain equipment with uniform bulk grain and no maintenance, which greatly reduces the losses caused by the vibration feeder damage;
- It is equipped with the most advanced transducer;
- According to different types of materials, it’s very convenient to adjust to optimum operation speed.
Specification
Model |
Width for magnetic election, mm |
Power, kW |
Capacity, t/h |
Weight, kg |
Overall size, mm |
---|---|---|---|---|---|
5CX-10 | 1300 | 1.5 | 10 |
960 |
1950х2065х2740 |
