5XFJ Series Vibration Grader
5XFJ Series Vibration Grader
Description
The vibration sieve can separate big and small impurities from all kinds of grain and seeds.The material can be classified into big, medium and small particles with different layers of sieves.
It is widely used in seed processing and agricultural product processing industry. Durable, Stable and Easy to handle.
Specification
| Model | Layer / Sieves |
Sieve size, mm |
Power, kW |
Capacity, t/h |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|
| 5XFJ-7.5CY | 4 / 8 | 1250х2400 | 1.1 | 7.5 | 1080 | 3500х2050х1880 |
| 5XFJ-7.5CCY | 4 / 12 | 1250х3600 | 1.5 | 7.5 | 1360 | 4630х2050х2050 |
| 5XFJ-10CY | 4 / 8 | 1500х2400 | 1.5 | 10 | 1210 | 3500х2300х1880 |
| 5XFJ-10DY | 5 / 10 | 1500х2400 | 1.5 | 10 | 1360 | 3550х2300х1740 |
| 5XFJ-20Y |
double screen box |
1500х2400 | 1.5 | 15-20 | 1360 | 3550х2300х1740 |
| 5XFJ-20C | 8 / 16 | 1500х2400 | 3 | 15-20 | 2800 | 4363х2375х4399 |
| 5XFJ-20AS | 8 / 16 | 1500х2400 | 3 | 30-40 | 3000 | 4161х2599х4502 |
| 5XFJ-30C | 12 / 24 | 1500х2400 | 4.5 | 20-30 | 4200 | 4387х2549х5435 |
