Model HNX220 Screw Oil Press
Used for pressing peanut, sunflower seed, rapeseed, sesame and rice bran.
Details
Characteristics
Capacity
—
10-12 T/D
Power
—
18.5 kW
Weighting error
—
6000 кг
Overall size
—
3100x1500x2800 mm
Model HNX220 Screw Oil Press
Description
Model HNX220 Screw Oil Press is a large continuous spiral oil press, designed for oil enterprises to choose the squeezing process under the high temperature. Suitable for peanut, sunflower seed, rapeseed, sesame and rice bran.The machine adopts the international advanced technology and materials. Its technical indicators fully meet the advanced level of modern-oil equipment.
This model is equipped with YE3 new energy saving motor. The main wearing parts of the pressing worm and cage bars are using the alloy material, the service life is 2-3 times of the ordinary material.
Specification
| Raw material |
Capacity, T/D |
Residual Oil Rate of Cake |
Power, kW |
Overall size, mm |
Weight, kg |
|---|---|---|---|---|---|
| Rapeseed | 10-12 | 5-8% | 18.5 | 3100x1500x2800 | 6000 |
| Sesame | 10-12 | 5-8% | 18.5 | 3100x1500x2800 | 6000 |
| Sunflower seed | 10-12 | 5-7% | 18.5 | 3100x1500x2800 | 6000 |
| Peanut | 10-12 | 5-6.5% | 18.5 | 3100x1500x2800 | 6000 |
