Single Phase Screw Air Compressor
Single Phase Screw Air Compressor
Advantage
The compressor contains a set of accurate and reliable ATS (automatic constant temperature devices), which keeps the temperature of the lubricating oil in a constant range after the air compressor is started, so as to ensure that the exhaust temperature of the air compressor reaches above the dew point temperature of the compressed air, and avoids the precipitation of condensed water.Specification
Variable Speed| Model | Power, kW |
Pressure, bar |
Capacity, m3/min |
Air Tank, L |
Outlet dimension |
Overall size, mm |
|---|---|---|---|---|---|---|
| SLTS-3.7V |
3.7 |
8 10 12.5 |
0.2-0.4 0.17-0.35 0.15-0.3 |
100 | G1/2 | 1020х540х1350 |
| SLTS-4.5V | 4.5 |
8 10 12.5 |
0.25-0.5 0.21-0.42 0.18-0.36 |
100 | G1/2 | 1020х540х1350 |
| SLTS-5.5V |
5.5 |
8 10 12.5 |
0.31-0.63 0.27-0.55 0.21-0.42 |
100 | G1/2 | 1020х540х1350 |
| SLTS-7.5V | 7.5 |
8 10 12.5 |
0.49-0.98 0.45-0.9 0.4-0.8 |
100 | G1/2 | 1060х560х1270 |
| SLTS-9V | 9 |
8 10 12.5 |
0.6-1.2 0.54-1.0 0.46-0.92 |
100 | G1/2 | 1300х580х1375 |
Fixed Speed
| Model | Power, kW |
Pressure, bar |
Capacity, m3/min |
Noise, dB | Air Tank, L | Exhaust port |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|---|---|
| SLTS-3F | 2.2 |
8 |
0.34 |
55 | 150 | RC1/2 | 76 | 640х400х640 |
| SLTS-3FS (200V) | 2.2 |
8 |
0.34 |
55 | 150 | RC1/2 | 79 | 640х400х640 |
| SLTS-6F | 4.5 |
8 |
0.65 |
60 | 150/220 | RC1/2 | 105 | 720х430х670 |
| SLTS-7F (200V) | 5.5 |
8 |
0.80 |
62 | 150/220 | RC1/2 | 110 | 720х430х670 |
| SLTS-10F | 7.5 |
8 |
1.05 |
65 | 290 | RC3/4 | 170 | 820х560х810 |
| SLTS-0413F | 3.0 | 12.5 |
0.34 |
57 | 150 | RC1/2 | 76 | 640х400х640 |
| SLTS-0413FS (200V) | 3.0 | 12.5 |
0.30 |
57 | 150 | RC1/2 | 79 |
640х400х640 |
| SLTS-613F | 4.5 | 12.5 |
0.60 |
61 | 150/220 | RC1/2 | 105 | 720х430х670 |
| SLTS-7FS13 (200V) | 5.5 | 12.5 |
0.66 |
62 | 150/220 | RC1/2 | 105 | 720х430х670 |
| SLTS-1013F | 7.5 |
12.5 |
0.95 |
66 | 290 | RC3/4 | 170 | 820х560х810 |
| SLTS-0616F | 4.5 | 16 |
0.34 |
65 |
|
RC3/4 | 90 | 720х430х670 |
| SLTS-1016F | 7.5 | 16 |
0.65 |
66 |
|
RC3/4 | 155 | 820х560х810 |
| SLTS-1516F | 11 | 16 | 1.05 | 68 |
|
RC3/4 | 190 | 820х560х810 |
| SLTS-06F | 4.5 | 8 |
0.65 |
66 | 290/420 | RC1/2 | 225 | 1320х600х1390 |
| SLTS-10F | 7.5 | 8 | 1.05 | 68 | 290/420 | RC1/2 | 290 |
1320х600х1390 |
