Oil Free Booster Compressor
Oil Free Booster Compressor
Advantages
- Automatic operation control; fault warning and shutdown protection, real-time display of operation status; memory display of failure shutdown, self-diagnosis;
- A built-in frequency converter can change the speed of the motor, make the compressor exhaust and customer demand accurately match, and ensure the lowest energy consumption.
Specification
| Model |
Power, kW |
Capacity, m3/min |
Inlet pressure, bar |
Outlet pressure, bar |
Weight, kg |
Overall size, mm |
Connection |
|---|---|---|---|---|---|---|---|
| SLT-15B | 15 | 4 | 10 | 30-40 | 1000 | 1700х1200х1850 | DN32 |
| SLT-30B | 30 | 6 | 8 | 30-40 | 1800 | 2000х1400х1650 | DN32 |
| SLT-37B | 37 | 8 | 10 | 30-40 | 2000 | 2000х1400х1650 | DN32 |
| SLT-45B | 45 | 10 | 8 | 30-40 | 2600 | 2600х1500х1850 | DN40 |
| SLT-55B | 55 | 12 | 10 | 30-40 | 2900 | 2600х1500х1850 | DN40 |
| SLT-75B | 75 | 16 | 8 | 30-40 | 3700 | 2800х1800х2100 | DN50 |
| SLT-90B | 90 | 20 | 8 | 30-40 | 3900 |
2800х1800х2100 |
DN65 |
| SLT-110B | 110 | 24 | 10 | 30-40 | 4100 | 2800х1800х2100 | DN80 |
