Diesel Portable Screw Air Compressor
Diesel Portable Screw Air Compressor
Description
Startup performance: When the ambient temperature is ≥ -10°C, the engine can start smoothly without any low temperature starting device.Specify working environmental conditions:
- Attitude: ≤ 1200 m
- Ambient temperature: from -10°C to 35°C
- Relative humidity: 60%
- Inclination of the site: ≤ 30°
Features
- The main engine and the diesel engine are directly connected through a high elastic coupling with the large diameter rotor design of the third generation 5:6, and there is no increasing gear in the middle. The speed of the main engine is the same as that of the diesel engine and the transmission effects achieved a higher rate, better reliability, longer-life for the new technology pull behind air compressor;
- The air volume control system is simple and reliable, according to the size of the air consumption, an air intake of 0~100% automatic adjustment. At the same time, automatic adjustment of the diesel engine throttle, maximum diesel saving;
- Microcomputer intelligent monitoring air compressor exhaust pressure, exhaust temperature, diesel engine speed, oil pressure, water temperature, oil tank level, and other operating parameters, with automatic alarm and shutdown protection function;
- Multi-stage air filter, suitable for dust environment; Multistage fuel filter, suitable for domestic oil quality status; Super large oil-water cooler, suitable for high temperature, especially high altitude, and another harsh environment;
- Easy to move. Each compressor is equipped with a lifting ring for safe and convenient lifting and transportation.
Specification
| Model |
Power, kW |
Capacity, m3/min |
Working pressure, bar |
Engine speed, rpm |
Exhaust temperature, °C |
Average fuel consumption, L/h |
Diesel fuel tank capacity, L |
Oil capacity, L |
Coolant capacity, L |
Noise, dB |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SLTDP-3/7 | 29 | 3.0 | 7 |
2300 |
≤65 | 6 | 60 | 6 | 11 | ≤94 | 900 | 2200х1600х1400 |
| SLTDP-5/7 | 37 | 5.2 | 7 |
2200 |
≤65 | 9 | 80 | 7 | 12 | ≤94 | 1400 | 2100х1650х1500 |
| SLTDP-7/7 | 55 | 8.0 | 8 |
2400 |
≤65 | 12 | 90 | 7 | 15 | ≤96 | 1300 | 2400х1760х1500 |
| SLTDP-10/8 | 70 | 10.0 | 8 |
2400 |
≤65 | 12 | 90 | 7 | 15 | ≤96 | 1400 |
2400х1760х1500 |
| SLTDP-13/10 | 92 | 13.0 | 8 |
2200 |
≤65 | 14 | 90 | 8 | 18 | ≤96 | 1600 | 2600х1760х1800 |
| SLTDP-16/8 | 132 | 17.4 | 8 |
2200 |
≤70 | 28 | 150 | 11 | 28 | ≤96 | 2900 | 3300х2000х2200 |
| SLTDP-16/15 | 140 | 17.0 | 16 |
2100 |
≤70 | 36 | 150 | 11 | 35 | ≤96 | 3800 | 3100х1960х2050 |
| SLTDP-15/13 | 140 | 17.0 | 13 |
2200 |
≤65 | 25 | 150 | 11 | 36 | ≤105 | 3500 | 3100х1950х1900 |
| SLTDP-17/8 | 140 | 17.4 | 8 |
2200 |
≤70 | 28 |
150 |
11 | 28 | ≤96 | 2900 |
3300х2000х2200 |
| SLTDP-17/13 | 140 | 17.0 | 13 |
2200 |
≤65 | 25 |
150 |
11 | 36 | ≤105 | 3500 |
3100х1950х1900 |
| SLTDP-18/17 | 162 | 18.0 | 17 |
2200 |
≤70 | 36 |
150 |
11 | 35 | ≤96 | 2500 | 3300х1900х2050 |
| SLTDP-21/13 | 162 | 21.0 | 12 |
2200 |
≤70 | 36 |
150 |
11 | 35 | ≤96 | 2500 |
3300х1900х2050 |
| SLTDP-18/20 | 162 | 18.0 | 22 |
2200 |
≤70 | 52 | 240 | 18 | 46 | ≤98 | 3800 | 3600х2100х2380 |
| SLTDP-20/20 | 191 | 18.0 | 22 |
2200 |
≤70 | 52 | 240 | 18 | 46 | ≤98 | 3800 |
3600х2100х2380 |
| SLTDP-20/25 | 228 | 23.0 | 25 |
2200 |
≤70 | 48 | 240 | 18 | 46 | ≤104 | 4500 | 3500х2140х2200 |
| SLTDP-24/22 | 228 | 26.0±5% | 25 |
1900 |
≤70 |
70 |
340 | 12 | 57 | ≤98 | 5200 | 4000х2240х2300 |
| SLTDP-29/25 | 310 | 33.6±5% | 25 |
1500 |
≤70 |
70 |
340 | 12 | 57 | ≤98 | 3800 |
4000х2240х2300 |
| SLTDP-31/25 | 310 | 33.6±5% | 25 |
1500 |
≤70 |
70 |
340 | 12 | 57 | ≤98 | 3800 |
4000х2240х2300 |
| SLTDP-35/30 | 410 | 35.0±5% | 30 |
1500 |
≤70 |
70 |
340 | 12 | 57 | ≤98 | 3800 | 4300х2240х2300 |
