Belt-type Color Sorter
Belt-type Color Sorter is used for sorting of low-bulk products: vegetables, fruits, ore, plastic, etc.
Details
Belt-type Color Sorter
Description
Belt-type Color Sorter is used for sorting of low-bulk products: vegetables, fruits, ore, plastic, etc.- The parts of the sorter that have direct contact with the product are made of stainless steel;
- The ability to complete with several vibratory feeders for a more uniform distribution of the product along the conveyor belt;
- The conveyor drive is controlled by the operator menu;
- RGB spectrum technology;
- The camera inspects the product almost 360°;
- Remote control;
- Intelligent control system interface;
- The working width of the conveyor belt is from 300 to 1300 mm.
Specification
| Model |
Capacity, t/h |
Channels |
Power, kW |
Voltage, V/Hz |
Pressure, MPa |
Air consumption, m3/min |
Weight, kg |
Overall size, mm |
|---|---|---|---|---|---|---|---|---|
| 6SXL-300KD2Y | 1.5-3.0 | 63 | 2.5 | 220/50 | 0.4-0.6 | 0.5-1.0 | 800 | 3530х1760х2066 |
| 6SXL-600KD2Y | 3.0-5.5 | 126 | 2.8 | 220/50 | 0.4-0.6 | 0.8-1.5 | 1080 | 3530х2100х2066 |
| 6SXL-1200KD2Y | 5.0-11.0 | 252 | 4.5 | 220/50 | 0.4-0.6 | 1.2-2.1 | 1510 | 3530х2700х2066 |
| 6SXL-300ZD2Y | 1.5-3.0 | 63 | 2.5 | 220/50 | 0.4-0.6 | 0.5-1.0 | 400 | 3325х1315х1520 |
| 6SXL-600ZD2Y | 3.0-5.5 | 126 | 2.8 | 220/50 | 0.4-0.6 | 0.8-1.5 | 600 | 3325х1630х1520 |
| 6SXL-1200ZD2Y | 5.5-11.0 | 252 | 4.5 | 220/50 | 0.4-0.6 | 1.2-2.1 | 1070 | 3325х2260х1520 |
